Krieger Sevac R063 / R100
The RV 063 is a higher capacity, high-efficiency rotary vane vacuum pump designed for medium to high capacity duty industrial applications.
Technical Specifications
| Parameter | R-063 | R-100 |
|---|---|---|
| Flow Rate at 50 Hz | 63 m³/h | 100 m³/h |
| Flow Rate at 60 Hz | 75 m³/h | 120 m³/h |
| Ultimate Vacuum | 50 Pa | 50 Pa |
| Motor Power | 2.2 kW | 3.0 kW |
| Inlet Diameter | G 1-1/4" | G 1-1/4" |
| Speed | 1440 rpm | 1440 rpm |
| Oil Volume | 2.0 L | 2.0 L |
| Weight | 75 kg | 82 kg |
| Noise Level | 68 dB(A) | 72 dB(A) |
| Cooling | Air | Air |
| Dimensions (L × W × H) | 655 × 405 × 285 mm | 715 × 400 × 295 mm |
